Infrastructure
Basic Electrical Engineering Laboratory |
High Voltage Laboratory |
Electrical Machine Laboratory |
Computer Laboratory |
PLC Laboratory |
Energy Research Centre |
 Project Laboratory |
High Voltage Laboratory |
Lab Investment till March 2023
| Sr. No. | Name of Laboratory | Amount (Rs.) |
| 1 | Electrical Machines laboratory | ₹ 12,94,445.00 |
| 2 | Basic Electrical Engineering laboratory | ₹ 14,07,931.00 |
| 3 | Electrical Measurements laboratory | ₹ 7,28,230.00 |
| 4 | Switch Gear and Protection laboratory | ₹ 11,40,082.00 |
| 5 | Power Electronics laboratory | ₹ 8,27,334.56 |
| 6 | High Voltage laboratory | ₹ 23,97,200.00 |
| 7 | Electrical Workshop | ₹ 2,77,878.00 |
| 8 | Control System laboratory | ₹ 4,20,320.00 |
| 9 | Network Analysis laboratory | ₹ 4,44,338.00 |
| 10 | Microprocessor & Interfacing laboratory | ₹ 4,09,164.00 |
| 11 | Project laboratory | ₹ 14,45,135.00 |
| 12 | Computer Facilities laboratory | ₹ 37,03,838.00 |
| 13 | PLC and SCADA laboratory | ₹ 4,86,455.00 |
| 14 | IOT laboratory | ₹ 2,64,832.00 |
| 15 | Research laboratory | ₹ 49,24,745.00 |
| 16 | Advanced Power Electronics laboratory | ₹ 2,10,530.00 |
| 17 | Advanced Drive laboratory | ₹ 10,45,573.00 |
| TOTAL | ₹ 2,14,28,031.00 |
Laboratory Details
| Sr. No. | Name of the Laboratory | Name of the Important Equipment | Total Lab Investment | ||
| 2020-21 | 2021-22 | 2022-23 | |||
| UG Laboratories | |||||
| 1 | Electrical Machines Laboratory | DC Motor # DC Generator Set (5HP, 220 V, 1500 RPM) # (3kW, 220 V, 1500 RPM) | 1138078.9 | 1281473.1 | 1294445 |
| 3-Ph Induction Motor # 3-Ph Alternator Set (440V, 2HP,1500 RPM # 1.5 kVA, 1500 RPM) | |||||
| Synchronous Motor # D.C. Generator Set (440V, 3HP, 1500 RPM # 1kW, 220V,1500 RPM) | |||||
| Induction Motor 3PH, Squirrel Cage (440 V, 1HP, 1500 RPM) | |||||
| Scharge Motor # D.C. Generator Set, (440V, 7.5HP, 660-2200RPM # 5.5kW, 220V) | |||||
| DC Shunt Motor # Alternator Set, (5HP, 220V,1500RPM # 3ph., 3.5kVA, 440V) | |||||
| 3-Ph Induction Motor # D.C. Generator Set (5HP, 440V, 1440 RPM # 3kW, 220V) | |||||
| D.C. Shunt Motor # Induction Generator Set (5HP, 220V, 1500 RPM # 440V, 1500 RPM) | |||||
| 3 phase Slip Ring Induction Motor (5HP, 1425 RPM) | |||||
| D.C. Shunt Motor # Alternator set (7.5HP, 220V,1500 RPM # 3PH, 5kVA, 440V) | |||||
| Synchronous Motor # D.C. Shunt Generator Set (3HP, 1500RPM # 2kW 220V,1500RPM) | |||||
| Synchronous Motor # Shunt Generator set (3HP # 2kW, 220V) | |||||
| DC Shunt Motor # Alternator (10 HP, 220 V, 35 A) # (7.5 kVA, 440/230 V) | |||||
| Synchronous motor, # DC Shunt Generator (3 Ph, 3HP, 1500 RPM) # (2 kW, 220V, 1500 RPM) | |||||
| Synchronous Motor # Shunt Generator (3ph, 3 HP) # (2 kW, 220 V) | |||||
| DC Motor # DC Generator (5 HP, 220 V, 1500 RPM) # (3 kW, 220 V, 1500 RPM) | |||||
| Voltage Stabilizer, 5 kW Input: 360 To 400 V, Output 400 V) | |||||
| 2 | High Voltage Laboratory | High Voltage Test Set (0-75kV, 5KVA) | 2397000 | 2397000 | 2397000 |
| High Voltage Break Down Tester ( 0-10kV) | |||||
| High Voltage D.C. Test Set (50 kV, 20 mA) | |||||
| High Voltage A.C. Test Set (0-150 kV, 100 mA) | |||||
| High Voltage, High pressure test chamber with vacuum pump 75 kV | |||||
| Motorized sphere gap arrangement | |||||
| Transformer Oil Test Kit 0-60kV, 1 kVA | |||||
| Salt fog chamber with compressor: 100KV | |||||
| Tesla Coil 50kV | |||||
| Oil Test System | |||||
| 100 kV DC Set without Transformer (100 kV Rectifier and 100 kV filter) | |||||
| Comparative Tracking equipment | |||||
| Capacitance Potential Divider, 150 KV | |||||
| Cockcroft waton voltage multiplier circuit (40kV) | |||||
| Impulse generator 5stages 150KV 225 Joules | |||||
| Insulation paper tester 0-30 kV, 1kVA | |||||
| 3 | Switch Gear and Protection Laboratory | Static Motor Protection Relay Type ITX 163-2 (220 V, 5 Amp) | 1140082 | 1140082 | 1140082 |
| Overcurrent Relay CDG 11A, (1.0A, EM, IDMT); | |||||
| Overcurrent Relay CTU 12 B (1.0A Static DTOC); | |||||
| Overcurrent Relay CDG 11 A (1.0A EM, IDMT); | |||||
| Overcurrent Relay CDG 14 A (1.0A EM, E/F Ex. Inv); | |||||
| Overcurrent Relay CDD 21 A (1.0A EM) | |||||
| Overcurrent Relay CAG 17 A (1.0A EM O/C Inst.) | |||||
| Overvoltage Relay VTU 21 A (1.0A Static DTOV) | |||||
| Differential Relay DDT 12 A (1.0A EM) | |||||
| Differential Relay DDT 32 E (1.0A, 3-Ph, EM) | |||||
| Impedance Relay ZTCM 12(1.0A Static) | |||||
| Admittance Relay YCG 14(1.0A EM) | |||||
| Reverse Power Relay (MRP-11, AC/DC, 1A, Static, Aux 230V,) | |||||
| Motor Protection Relay (MPR-300,230V,1A | |||||
| Static, Aux.230V,) | |||||
| Transformer Differential Relay, (CT-Sec-1 A, Static, 1 Pole, 2 Wdg) | |||||
| Air Circuit Breaker | |||||
| (3 Pole, 800 A, MDO) | |||||
| Earth Leakage Relay With CBCT(2/8A); | |||||
| Relay Test Set | |||||
| Phase Shifting Transformer | |||||
| Impedance Relay Test Kit Model TK-IMP | |||||
| 4 | Project Laboratory | Power Quality Analyzer, HIOKI make, 3196, with Accessories | 1696082.9 | 1696082.9 | 1441535 |
| Digital Storage Oscilloscope, TPS2024B 200 MHz with Current and High Voltage Probes: 2 No | |||||
| High speed looger with sensors for Electrical Machine Conditioning monitoring | |||||
| Super capacitor: 10F, 2.7V, 50F, 2.7V | |||||
| 100F, 2.7V | |||||
| DSP Development Tools TMDX28069USB | |||||
| Microcontroller Insystem Emulator | |||||
| High Speed Data Logger: USB-4711A-AE 150KS/s 12bit USB Multifunction module | |||||
| BLDC Motor: Rated Power 50W, Torque-0.11Nm, RPM-3000, 24V DC | |||||
| Function Generator / Pulse 20MHZ Model- M-2019 | |||||
| 5 | Power Electronic Laboratory | V/F Controller for Three Phase Induction motor | 827334 | 827334 | 827334 |
| Single Phase Half controlled converter with motor load | |||||
| Single Phase Inverter Trainer Kit,1KVA | |||||
| Three Phase Inverter Trainer Kit | |||||
| Buck Converter Trainer Kit | |||||
| Boost Converter Trainer Kit | |||||
| DC Drive Trainer Using Dual Converter with Motor | |||||
| Power scope 33055P1 | |||||
| 20 MHz, 1000V, Dual Channel : 8 No | |||||
| 6 | Microcontroller / Microprocessor and Interfacing Laboratory | 8085 A Microprocessor Trainer Kits: 15 No | 409164 | 409164 | 409164 |
| 8051 Microcontroller Trainer Kit: 10 No | |||||
| ATMega32 Microcontroller Trainer Kits: 15 No | |||||
| Simulator for 8051 microcontrollers: 3 No | |||||
| 7 | Control System Laboratory | DC Position Control Setup: 2 No | 399675 | 399675 | 420330 |
| AC Servomotor Characterizations kit | |||||
| PID Temperature Controller kit | |||||
| DC Motor Speed Control Unit | |||||
| Linear System Simulator | |||||
| 8 | Network Analysis Laboratory | Digital LCR meter | 444338 | 444338 | 444338 |
| Reciprocity Theorem kit | |||||
| Tellegen’s Theorem kit | |||||
| Two Port Network Parameters kit | |||||
| Thevenin’s & Norton’s Theorem kits | |||||
| Superposition Theorem | |||||
| Series & Parallel Resonance kit | |||||
| Constant K-Type Filters | |||||
| Dual Channel Oscilloscope with component tester | |||||
| 10MHZ Multifunction Generator | |||||
| 9 | Electrical measurement and instrumentation Laboratory | Hay’s Bridge | 648976.55 | 648976.55 | 728230 |
| Kelvin’s Double Bridge | |||||
| Wheat Stone Bridge | |||||
| Owen’s Bridge | |||||
| Anderson’s Bridge kit | |||||
| Schering Bridge | |||||
| Current Transformer Test Set | |||||
| LVDT trainer kit | |||||
| Piezoresistive Pressure Measurement kit | |||||
| Thermocouple kit | |||||
| Flow measurement using Rotameter Setup | |||||
| 10 | PLC Laboratory | Siemens S7-1215C PLC based Trainer Kit: 06 No | – | – | 433088 |
| Sematic HMI KTP700: 1 No | |||||
| Sensor & Actuation Modules: 2 No | |||||
| PLC Communication Card: 2 No | |||||
| 11 | Computer Facilities Laboratory | MATLAB 2014 version No of licenses- 05 | 3443370 | 3443370 | 3443370 |
| DSA Tool EDU 3.7 32-bit version: all VSAT PSAT SSAT No of licences-05 | |||||
| ETAP 7.0 version software 50 Bus | |||||
| 12 | Basic Electrical Engineering Laboratory | Synchronous motor Working cut out section | 1497800.5 | 1497800.5 | 1407931 |
| Shunt Motor Working cut out section | |||||
| Shunt motor 1HP/220V | |||||
| Universal BH Curve Tracer | |||||
| Rectifier Unit : I/P-3Phase,440V AC | |||||
| O/P 0-250V DC 40Amps | |||||
| Rectifier Unit I/P-3 Phase,440V AC O/P: 0-250V DC 60Amps | |||||
| Dual Channel power scope :20MHz: 5 No | |||||
| Single phase Inductive load, 1Phase, 240V ,10 A, 50Hz :2 No | |||||
| Single phase Capacitive load bank: 1Phase, 240 V, 10A, 50Hz: 2 No | |||||
| Single phase resistive load bank: 2kW: 2 No | |||||
| 13 | Electrical Workshop | Automatic coil winding M/C, Bench Model-5, Digital-Mechanical Resistable counter pully block | 277878 | 277878 | 277878 |
| Hand operated Winding Machine | |||||
| Manual single coil winding machine | |||||
| 14 | IOT Laboratory | AL/ML Board with Camera Accessories | |||
| IOT gateway | |||||
| IOT sensor Kit -sensor booster Pack | |||||
| Finger Print Module with dragon Development board | |||||
| IDE configured For Cortex Platform Cross works For Arm Electronically | |||||
| IoT Gateway | |||||
| TMS320F283790 Launch Pad Development Kit | |||||
| PG Laboratories | |||||
| 15 | Research Laboratory | 5439804 | 5439804 | 5439804 | |
| 16 | Advanced Power Electronics Laboratory | DC-DC buck converter 100W | 210530 | 210530 | 210530 |
| DC-DC SEPIC Converter | |||||
| Dual IGBT protected device module | |||||
| Cycloconverter single phase with R & RL loads, Digital multimeter | |||||
| DC-DC sepic converter Input voltage: 0-50V DC output Voltage 0-24V DC LCD Display for input output voltage & current Programmable with MPPT or without MPPT Control | |||||
| Single Phase Bridge Inverter with R and RL load with a) Single Phase IGBT Module Model PEC16M3 b) Single Phase inverter Control Module Model PEC16M4#1 with Single Phase | |||||
| 17 | Advanced Drive Laboratory | Variable Speed AC Motor drive | – | – | 1045573 |
| coupled 750Wmotor with shunt generator 220V DC,1500 rpm | |||||
| Power Quality Analyzer, HIOKI make, 3196 | |||||
| 1)PMSM Control Module with Controller, software, rectifier, Inverter with Electrical Loading & speed Sensor feedback a) TMS 320F28335 based DSP Controller Board b) IPM based Power Module 3 Hp (PEC 16DSOMO-1) c) 1 Hp PMSM Motor DC generator load set up with encoder sensor. | |||||
| DC Motor Speed Controller with 3φ SCR Bridge Dc motor with generator, speed measurement arrangement firing ckt for SCr bridge a) 3 phase SCR power Ckt (PEC 14HV5P) b) Chopper/Inverter PWM Controller (PEC 16HV2B) c) 1Hp DC Shunt Motor DC Shunt Generator set up with QEP Sensor (PEC 16DCGQ1) | |||||
| Variable Speed drive Panel | |||||
